GS20 Sliding Doors
GS20 Sliding Doors
Take your next project to the next level with our GS20 slimline sliding patio doors. Our team of experts manufacture and supply our trade products across the UK. Use our quoting engine below for supply only sliding patio door prices now!
Natual Light
Embedded Options
Weatherproofed
Get your quote:
mm x mm
1. Width: Measure horizontally across the opening from edge to edge at the top, middle, and bottom. Use the smallest measurement.
2. Height: Measure vertically from top to bottom on the left, center, and right sides. Use the smallest measurement.
1 pane
1. Width: Measure horizontally across the opening from edge to edge at the top, middle, and bottom. Use the smallest measurement.
2. Height: Measure vertically from top to bottom on the left, center, and right sides. Use the smallest measurement.
Grey
1. Width: Measure horizontally across the opening from edge to edge at the top, middle, and bottom. Use the smallest measurement.
2. Height: Measure vertically from top to bottom on the left, center, and right sides. Use the smallest measurement.
Need to talk to an expert? Get in touch
Overview
Glazing Thickness up to 30mm
Our aluminium sliding doors feature a glazing thickness as thick as 30mm. With this level of glazing, our slimline sliding patio doors will offer thermally efficient and weatherproof performance.
Up to Six Sashes Available
Choose the right amount of sashes for the slimline sliding patio doors you require with our range of sash options. You can choose as many as six aluminium sliding patio doors to fit your commercial/trade projects.
20mm Sightline
Our aluminium patio doors use slim frameworks and minimalist designs to create a sleek and elegant style. If you’re looking to give your project an injection of modern style, try our slimline patio sliding doors. They are a known favourite across both retail, and commercial sectors.
Low U-value Glazing
The glazing featured in our aluminium sliding glass doors has been designed to provide the very best energy efficiency. With a U-value of 1.3 W/m²K our slimline sliding patio doors contribute to heat retention. Allow your customer’s peace of mind with our high quality patio doors!
Noise Reduction Glass
Another benefit of our sliding patio doors with double glazing is the soundproofing quality they provide. Cutting as much as 41 dB noise out of the home, these slimline sliding patio doors will induce quiet.
Effortless Operation
Thanks to the aluminium construction of our slimline sliding patio doors, they open with casual ease. Their mechanisms will stay smooth and efficient even after years of use. Your project is meant to last, let our high quality slimline doors do the same.
.jpg)
Stunning Design Slimline Sliding Patio Doors
Living up to their name, our slimline sliding patio doors feature a minimalist profile. This suits both modern and traditional homes perfectly, creating a non intrusive design for your project. With such slim sightlines, these aluminium patio doors look incredibly aesthetic.
Another benefit of such slim sightlines is the emphasis placed on their large glass areas. Allowing the largest amounts of natural light to flood into your customers home, these aluminium patio doors create a bright and inviting environment.
.jpg)
Long Lasting Slimline Sliding Patio Doors
When choosing a new door solution for your customer’s home, you want to be assured of longevity. Aluminium patio doors are a great option in this regard. They’re built with the highest-quality materials and the latest production methods. Often, slimline sliding patio doors provide decades of high performance.
Being made of a durable and hard-wearing material, slimline sliding patio doors offer resistance against the elements and intruders in equal measure. Featuring the latest state-of-the art locking mechanisms, these aluminium patio doors will keep your customer’s home safe and secure.
.jpg)
Why Our Aluminium Slimline Doors Are Perfect For Your Next Projects!
Slimline sliding doors are an excellent choice for trade projects due to their sleek design and superior functionality. These doors provide a modern, minimalist aesthetic that enhances the visual appeal of any space, making them a popular option for contemporary builds. Their slim frames maximize natural light, creating bright and inviting interiors that are highly sought after in both residential and commercial properties.
Additionally, slimline sliding doors are crafted with advanced materials and technology, ensuring durability and energy efficiency, which are crucial factors in trade projects. They also offer smooth operation and space-saving benefits, as they do not require the swing space of traditional doors. With customizable options to fit various project requirements, slimline sliding doors are a versatile and practical solution for any trade professional looking to deliver high-quality, stylish, and efficient building solutions.
Options
Handle colours
Technical specifications
General
Sash sight line 20mm
Quality assured BSI Kitemark Standards
Possibility to embed frames within the wall
Up to 4 rails
Thermally broken
Possibility of sash encounters at a 90o corner without a mullion
Panel width 800-2500mm
Maximum panel height 3000mm
Maximum panel weight 320kg
Maximum glazing thickness 30mm
Test data
U value from 1.3 (W/m2K)
Maximum acoustic insulation 41Db
Air permeability (EN 12207): Class 4* (600Pa)
Water tightness (EN 12208): Class 7A* (300Pa)
Wind resistance (EN 12210): Class C5* (2000Pa)
*Reference test Balcony 1.23 x 1.55m. 1 sash + 1 fixed light.
Colour Finishes
Available from Glideline
Powder Coating RAL Finish
Standard 7016M and 9005M, 9010G
Available in 150+ RAL finishes
Textured finish available
Split colour for interior/exterior
Anodized aluminium
Class 15; 15-19 micrometer coating for external use as standard
Class 20; 20-24 micrometer coating for use in aggressive conditions, industrial areas and marine pollution
Silver brushed, silver rough brushed, bright silver, matte silver, brushed steel, rough brushed steel, brushed champagne re-polished, bright gold, rough brushed inox re-polished, brushed stainless steel, rough brushed ivory re-polished, brushed bronze, rough brushed bronze and re-polished, rough brushed copper re-polished, rough brushed Bordeaux re-polished, rough brushed green, rough brushed blue re-polished, rough brushed grey re-polished, matte black
Reviews
Glideline installed 6 sets of sliding doors in our house. This was a major investment for us so we wanted it to be just right. David and all the team were friendly and helpful from start to finish. Henry was great.
Thank you to the installers Joe and Luke for their hard work. It wasn't easy going up all the stairs but they were happy doing so and I couldn't be happier with the doors. Also Henry has been fantastic from sta…
FAQs
What’s the maximum weight?
Our aluminium patio sliding doors can handle weights up to 320 Kg, which allows for wide door spans for your trade project. This enables several configuration options for homeowners, as well as our trade customers.
How thermally efficient are they?
These slimline sliding patio doors have U-values as low as 1.3 W/m²K, contributing to the energy efficiency of homes. This helps ensure bills are at their lowest possible value.
Do they work in traditional homes?
Slimline sliding patio doors have a minimalist profile as well as a timeless design. These aluminium doors will work perfectly in modern or traditional homes as a result.
If we haven’t answered your question, Send us a message
